How to choose the thickness of

There are many types of conveyor belts, which will make it more difficult to purchase. Especially for the new recruits, they may choose the material, know how long and how wide they are, and they are very confused about how thick they are, because too thick and too thin conveyor belts will affect the use effect of conveyor belts. Next, the conveyor belt manufacturers for this problem to introduce.


Select the thickness according to the size of conveyor roller:


The following parameters are for reference only. (the thin PVC conveyor belt can choose the one with larger roller, but the small one cannot choose the thick one.)


1. For the roller with diameter of 40mm, one cloth and one glue 1mm thick conveyor belt is selected.


2. For the roller with diameter of 60mm, two cloth and two glue 2mm thick conveyor belt is selected.


3. The roller with diameter of 90mm adopts 3mm thick conveyor belt with two cloth and two glue.


4. The roller with diameter of 120mm adopts 4mm thick conveyor belt with three cloth and three glue.


5. For the roller with diameter of 150 mm, three cloth and three glue 5 mm thick conveyor belt shall be selected.


Select the thickness according to the length of the pipeline


It is recommended that the longer the belt is, the thicker it is. The shorter one can also choose the thicker one. This one should be selected according to the weight of the transported goods. If the transported goods are very light and the rollers meet the requirements, the thicker PVC conveyor belt is recommended here, and the service life can be longer. If you choose the cost-effective one, you can also choose the thinner one. 2mm and 3mm are common here.


If you don't know how to choose, you can contact our online customer service to inform our customer service of the length, width and items of PVC conveyor belt, and we will recommend the thickness to you.


The thickness of PVC conveyor belt is selected according to the ring shape


1. First of all, you need to know what materials you want to transport, whether you need anti-static, whether you want to wear-resistant and other characteristics, the choice of width, thickness, the general PVC conveyor belt has 1.0 mm ~ 6.0 mm to choose from.


2. If you need to climb, you can choose the conveyor belt with pattern. The pattern can increase the friction between the PVC conveyor belt and the material, so as to realize the climbing conveying. The thickness is generally 3mm-5mm.


3. Conveyor belt can be divided into different colors (red, yellow, green, blue, gray, white, black, dark blue, green, transparent), thickness products, thickness from 1.0 mm to 6.0 mm can be produced.


The above is about how to choose the thickness of PVC conveyor belt, I believe you also have a certain understanding. Welcome new and old customers to inquire.
